Mechanical set Packers
ASI-X Packer
A high-performance, mechanically set retrievable packer built for versatility across production, injection, and testing applications.
The ASI-X Packer is the most adaptable mechanical set packer in the lineup, suitable for use in virtually any production scenario—whether for injection, treating, or testing in both shallow and deep wells. This tool can be set and operated in tension, compression, or neutral position based on well demands, offering maximum flexibility. Its large internal by-pass minimizes swabbing and enables effective pressure equalization by opening prior to releasing the upper slips. The packer features a simple ¼-turn right-hand set and release system via its J-slot mechanism. Available in standard and high-temperature (HT) models, the ASI-X can handle differential pressures up to 10,000 PSI, making it ideal for high-pressure production environments where long-term deployment is needed.
Special Features
- Internal by-pass below upper slips allows debris to wash out during retrieval
- By-pass opens before slip release to equalize pressure
- Operates in tension, compression, or neutral—ideal for varying well conditions
- Simple ¼-turn right-hand set and release with J-slot design
- HT version available for up to 10,000 PSI differential pressure
- Optional J-slot arrangements to meet specific application requirements
- Suitable for both shallow and deep well operations
